2019 Latest Version XPROG X-PROG Box V6.12 XPROG-M ECU Programmer With USB Dongle
- New Generation Hardware, runs more steady and faster than old version.
- Latest software version: V6.12
- Add new authorization: AUTH-0028-3 Renesas RL78 Authorized and AUTH-0028-4 Renesas M32C Authorized
- Language: English
- Operating system: WinXP/Win7/Win8
XPROG V6.12 using tips:
- XPROG V6.12 dongle isn't compatible with older version Xprog.
- Please Close all anti-virus software in your computer, becase the anti-virus software will kill Xprog V6.12 driver.
- Disconnect internet. If not, the internet may damage XPROG hardware.
- Uninstall all the old version XPROG software before you install V6.12 software, because XPROG V6.12 hardware is not compatible with other version XPROG software.
- Never try to UPDATE it, the hardware will be damaged if you try to update it online.
Please windows system required as below:
- Windows system should be windows XP 32bit OR windows 7 64 bit, all the patch software for the windows system should be installed already and the windows properly works well...
- The windows system should be with at lest 2 partitions (except the CD ROM.)
- Can not be working with virtual harddisk.
Install manual in words:
- Click the file "installation.reg", get the file information to the regedit.
- Install the file "AdbeRdr11000_zh_CN.exe", it is a must, otherwise the Xprog software will not start.
- Plug the Xprog main interface to the computer, install the USB driver.
- Copy the folder "XPROG-BOX6.12" to the desktop, and open it, and run the "xprogdesktop.exe", then software open.
XPROG V6.12 Authorizations:
AUTH-0001 Motorola HC05 family authorization (allows to read/write EEPROM)
AUTH-0002 Motorola HC08 family authorization (allows to read/write EEPROM)
AUTH-0003 Motorola HC11 family authorization (allows to read/write EEPROM)
AUTH-0004 Motorola HC12, 9S12 family authorization (allows to read/write EEPROM and flash memory)
AUTH-0005 Texas Instruments TMS370/TMS374 family authorization (allows to read/write EEPROM)
AUTH-0006 Motorola HC05Bxx and HC05Xxx family bypass security authorization (allows to read/write secured EEPROM and flash memory)
AUTH-0007 ST M35080 authorization. Read/Write/Erase device to delivery state.
AUTH-0008 BMW EWS3 authorization
AUTH-0009 ATMEGA family authorization (allows to read/write EEPROM and flash memory)
AUTH-0010 MB ZGS001 authorization
AUTH-0011 Motorola HC11EA9/E9 bypass security authorization (allows to bypass security bit and read EEPROM and RAM memory)
AUTH-0012 National CR16 authorization (allows to read/write EEPROM memory)
AUTH-0014 ST7, ST10 family authorization (allows to read/write internal flash)
AUTH-0015 MPC5xx authorization (depending on device program automatically detects MPC5xx, M95xxx device type, flash, external flash and configuration memory size)
AUTH-0018 Motorola HC12, HC912, MC9S12, MC9S12X bypass security authorization (allows to read/write secured EEPROM and flash memory)
AUTH-0020 ARM (Micronas, ...) Family authorization (allows to read/write internal flash and external serial EEPROM)
AUTH-0021 ARM (Micronas, ...) Family bypass security authorization (allows to read/write secured and non-secured internal flash and external serial EEPROM, view/change mileage, Chassis number (VIN), serial number and PIN code).
AUTH-0024-3 9S12XE SECURITY
AUTH-0025-1 MPC/SPC5xxx Authorized 2016/3/13
Newly added below 4 adapters:
ADP-0006 M35080 ICP adapter
QFP64 MC908AZ/AS60 3K85K adapter
ADP-0001 TMS370 PLCC28 programming adapter
ADP-0002 TMS370 PLCC44 programming adapter
ADP-0003 TMS370 PLCC68 programming adapter
ADP-0004 Motorola HC05B/X PLCC52 programming adapter
ADP-0005 Motorola HC05B/X QFP64 programming adapter
ADP-0006 ST M35080 in-circuit programming adapter
ADP-0008 TMS374 family in-circuit programming adapter
ADP-0009 MC68HC05V12 programming adapter
ADP-0010 TMS374 on-board programming adapter
ADP-0011 HC11EA9/E9 programming adapter
ADP-0017 HC(S)12 BDM / ARM Micronas in-circuit programming/bypass security adapter
Additional adaptor for 5M48H P-Flash
- 1pc x XPROG-Box Hardware (Aluminum Enclosure)
- 19pc x Adapters Set
- 1pc x USB Cable
- 1pc x 16Pin cable
- 1pc x CD with XPROG-Box Software (V6.12)
XPROG-M V6.12 Software Add some functions A PART Display:
