Xhorse VVDI Mini Key Tool Remote Key Programmer – Global Version for iOS and Android

Key Highlights

1. Super-Fast Frequency Test: Operates at 300–450 MHz with a detection distance of up to 30 cm.
2. Extensive Vehicle Database: Supports a wide range of car models.
3. Mobile App Integration: Connects via Bluetooth to both iOS and Android devices for convenient operation.
4. Fast Chip Reading: Quickly retrieves transponder chip information.
5. Free 48 Transponder (96-bit) Copying: Includes one year of free authorization for copying 48 transponders (96-bit).
6. Frequent Updates: Regular software and database updates.
7. Online Customer Support: Access technical assistance when needed.
8. Multilingual Xhorse App: Available in English, Spanish, French, Thai, Polish, Italian, Portuguese, Hindi, Hebrew, and Chinese.

What You Get When You Order Now

• Free Copy 48 Transponder (96-bit) Authorization!
• Free 1-Year Token for 96-bit ID48 Copy (1 token per day)!
• Free Toyota H Transponder Generation License!

Update your device to the latest version to freely switch between all supported languages:

Xhorse MINI Key Tool Functions

Transponder Editing & Cloning

Detects most immobilizer transponders and supports editing and cloning of common transponder types on the market.

Transponder Generation

Supports TP transponders and select special transponders across more than 700 vehicle models, helping reduce transponder inventory needs.

Remote Generation

Compatible with 128 brands and over 2,000 vehicle models. Provides comprehensive data including key images, transponder types, key blanks, and remote matching details.

Remote Cloning

Supports HCS and fixed-code cloning, non-HCS rolling code cloning, and editing for PT22XX, LX918, HT6P20, VD5026, AX5326, and HT12X fixed codes.

Garage Remote Generation

Supports more than 100 garage remote types.

Frequency Testing

Performs power testing within the 300–450 MHz frequency range.

Toyota H Transponder Support

Activates the Toyota H transponder generation function.

Special Functions

1. Unlock Toyota smart keys
2. ID63 to ID83 conversion
3. Special 4D to 4C conversion
4. Remote detection

VVDI Super Chip Configuration

Set the type of VVDI super chip.

Full Functionality with All Activations

With full authorization, the VVDI Mini Key Tool enables:

• AI – Car remote type
• AI – Key blade type
• AI – PIN code
• Remote – Vehicle remote
• Remote – Garage remote
• Remote – Proximity remote
• Generate transponder – 7935 / 46 / 4D / 48 / 8C
• Generate transponder – For Toyota H (8A)
• Transponder clone – ID48 (96 bits)
• Transponder clone – ID46
• Transponder clone – ID4D
• Transponder clone – ID4E
• Transponder clone – ID70 / 83
• Transponder clone – ID11 / 12 / 13 / 4C / 8C
• Transponder clone – For Toyota / Daihatsu G
• Transponder clone – For Toyota H (8A)
• Transponder clone – ID33 / 42
• Transponder edit – 11 / 12 / 13 / 4C
• Transponder edit – 46 / 47 / 48 / 4D / 4E
• Remote clone – Fixed code
• Remote clone – Rolling code
• Remote clone – Make new
• Detect remote frequency
• Set type of VVDI super transponder
• VVDI Special TP
• Special 4D to 4C
• Unlock Toyota smart key
• ID63 to ID83
• For Hyundai / KIA PIN code
• Copy BYD smart key
• Detect ignition coil signal
• Online technical support
• Technical center
• Video center
• History

How to Combine VVDI MINI KEY TOOL with DOLPHIN or KEY TOOL

Log in to the Xhorse app, connect your device via Bluetooth, and go to “Device & History” to combine devices.

How to Update the Xhorse VVDI Mini Key Tool

1. Connect the Xhorse MINI Key Tool to your computer using a USB cable.
2. Launch the Xhorse Update Kit software, select “VVDI Lark,” and click “Find Device.”
3. Once the device is found, click “Upgrade.”
4. Complete the update process.
5. Update the Xhorse app database for the VVDI MINI Key Tool.

Start the VVDI MINI Key Tool and connect it to the Xhorse app via Bluetooth.

How to Change Language on the VVDI Mini Key Tool

Technical Specifications

• OLED Size: 0.91”
• OLED Resolution: 128 × 32
• Power Input: 5V / 1A
• Usage Time: ≥10 hours
• Product Dimensions: 140 × 64.5 × 23.5 mm
• Weight: 86 g
• Charge Current: 650 mA
• Battery Capacity: 850 mAh
• Battery Voltage: 3.6–4.2 V

VVDI Mini Key Tool vs. VVDI KEY TOOL

Advantages of the Mini Key Tool

• Compact, lightweight, and highly portable
• Easy app-based updates—most updates are handled directly through the mobile application
• Designed for modern mobile internet use
• Fast startup and operation (e.g., frequency test in 20 seconds)

Limitations of the Mini Key Tool

• Requires both power and network connectivity
• Cannot operate without a connected phone and stable connection

Similarities

Both the VVDI Mini Key Tool and VVDI KEY TOOL offer identical capabilities for remote and transponder generation and copying.

Key Differences

1. VVDI KEY TOOL:

   • Operates independently—can perform all functions offline except online-dependent tasks like 46/4D copying
   • Offers additional features such as remote renew functions
   • Includes built-in Bluetooth
   • Equipped with a high-capacity battery

2. VVDI Mini Key Tool:

   • No internal battery or Bluetooth
   • Requires connection to a smartphone to function

Important Note

The VVDI KEY TOOL continues to receive regular updates even after the release of the VVDI Mini Key Tool.
