engineDance X5 Diag Truck Diagnostics

engineDance X5 Diag Truck Diagnostics for Light Trucks, Heavy Trucks, Buses, Agricultural Machinery, Construction Machinery

Product Features:

• Support more than 99.9% Chinese Brands vehicles.
• Cover European, Japanese and Korean brand vehicles.
• Wide coverage: Light trucks, heavy trucks, buses, agricultural machinery, construction machinery.
• Full-system diagnostics: Not only engine, support also AMT, ABS, EBS, VCU...
• Intelligently identify ECU
• Read and Erase fault code
• Actual values and Actuators

Special Functions:

• Injector coding
• Engine brake programming
• Transmission adapter learning
• Cylinder cutoff
• Cylinder compression test
• DPF forced regeneration
• Recording DCT date clearing
• Clutch adjustment
• Accumulation data clearing
• Fuel consumption data reset
• Engine oil distance reset
• Parameters calibration
• Idle speed setting
• Idle shutdown timer

Supported Vehicle Brands:

Chinese Vehicle Brands:

• FAW
• SITRAK
• FOTON
• SHACMAN
• SANY
• QINGLING
• DONGFENG
• JAC
• JMC
• XCMG
• SAICHONGYAN
• GOLDEN
• DAYUN
• CAMC
• CHENG LONG
• C&C TRUCK
• CDW
• CHANG AN
• YUE JIN
• KAMA
• TANGJUN
• WUZHENG
• WAW
• NAN JUN
• Zonda
• Mercedes-Zenz
• JINBEI
• LIFAN
• BAIC Truck
• DAEWOO
• YOUNGMAN

European Vehicle Brands:

• Scania
• MAN
• VOLVO
• DAF
• BENZ
• IVECO
• VW
• LANROVER
• JEEP
• KAMAZ

Japanese & Korean Brands:

• ISUZU
• HINO
• FUSO
• NISSAN
• Hyundai
• Kia
• HITACHI
• TOYOTA

Construction & Agriculture Machinery:

• HITACHI
• KOMATSU
• VOLVO
• CAT
• SANY
• ZOOMLION
• XCMG
• KATO
• JOHNDEERE
• KOBELCO
• Hyundai
• CASE
• RIESEDE
• YTO
• DOOSAN

Engine & ECU:

• WEICHAI
• YUCHAI
• FAW/DEUTZ
• CUMMINS
• YUNNEI
• DCD
• QUANCHAI
• SDEC
• CHANGCHAI
• DEUTZ
• ISUZU
• BOSCH
• CONTINENTAL
• DENSO
• DELPHI
• SIDA
• PXC

EngineDance X5 Exclusive technology Remote Unlock Encrypted MD1 ECU

(Notice: Paid feature: $100 for one remote unlock,one time.)

X5 ECU Programming List

Scania:

• EMS/EDC S6 250Kbps (MPC555/556)
• EMS S6 500Kbps (MPC555/556)
• EMS S8 250Kbps (MPC5566)
• EMS S8/EMD1 500Kbps (MPC5566)
• EMS S8/EMD1 250Kbps (MPC5566) –Bam
• EMS S8/EMD1 500Kbps (MPC5566) –Bam

Volvo Truck:

• EMS2.0(MPC56X)-OBD
• EMS2.2(MPC5554)-Bam
• EMS2.2(MPC5554)- Bench
• EMS2.3(MPC5674F)- Bench
• EMS2.4(MPC5777C)- Bench

MAN:

• Bosch EDC7C32 [0281020067]-OBD/Bench
• Bosch EDC17CV42 [0281020273, TC1797]- Bench
• MD1CE100 TC299- Bench

Ford Transit /Ranger, Land Rover Defender:

• SID208- Bench/ Bam
• SID209-OPEN
• SID208 OBD/Bench / Bam
• SID209 OBD/Open
• SID604 OBD writing, checksum

Denso:

• SH725XX/1N83M/ SH705X Bench
• 1N83M FLASH Reading, writing, checksum correction
• 1N83M EEPROM Reading, writing
• SH72543 FLASH Reading, writing, checksum correction
• SH72543 EEPROM Reading, writing
• SH7055 FLASH Reading, writing, checksum correction
• SH7055 EEPROM Reading, writing
• SH7058 FLASH Reading, writing, checksum correction
• SH7058 EEPROM Reading, writing
• SH7059 FLASH Reading, writing, checksum correction
• SH7059 EEPROM Reading, writing

TOYOTA/Lexus/Scion/Hino Gen 2:

• 76F0196/198/199/219 P5-CAN-bus
• 76F0199 GearBox P5-CAN-bus

TOYOTA/Lexus Gen 3:

• R7F701202/R7F701216 P5-UDS
• LC300/LX500d 3.3TD P5-UDS (F33A-FTV/R7F701216)
• LC300/LX500d 3.3TD MCU #2 P5-UDS (F33A-FTV/R7F701216)
• LC150/Hiace/Hilux/Revo/Fortuner 2.4TD, 2.8TD P5-UDS (1GD-FTV/2GD-FTV/R7F701216)
• LC150/Hiace/Hilux/Revo/Fortuner 2.4TD, 2.8TD 6AT Gearbox P5-UDS (AC60F/R7F701201)
• Camry/ES/Rav4/UX 2.0L, 2.5L P5-UDS (M20A-FKS/A25A-FKS/R7F701202)
• Camry/ES/Rav4 2.5L 8AT Gearbox P5-UDS (UB80/R7F701201)
• Camry/ES/Rav4 2.5L HV P5-UDS (A25A-FXS/R7F701202) [Test]
• Corolla 2.0L P5-UDS (M20A-FKS/R7F701202) [Test]
• Highlander/Siena 2.5L HV P5-UDS (A25A-FXS/R7F701216) [Test]
• Yaris GR 1.6T P5-UDS (G16E-GTS/R7F701216) [Test] [RD/WR/CK]

DELPHI:

• DCM3.2/DCM6.2AP/DCM6.24
• DCM7.1AP/ DCM7.24
• Dongfeng M9T DCM7.1AP
• Great Wall/Haval DCM6.2AP
• HYCET Great Wall/ZhongXin/Changan Kaicene DCM7.1AP
• Great Wall/Haval DCM3.7AP
• Kia/Hyundai DCM3.7AP(SH725xx)
• DOOSAN/Bobcat/Kioti/McCormick DCM3.7AP
• SsangYong 2.0L XDI DCM3.7AP
• DOOSAN/Bobcat/Kioti/McCormick (DCM3.7AP)
• GM/Opel/Chevrolet 2.0L, 2.2L CDTI (DCM3.7AP)
• JAC DCM6.2AP
• Qingling/Isuzu DCM6.2AP
• Qingling/Isuzu DCM7.1AP
• Yunnei DCM6.24
• Yunnei DCM7.24
• Changan DCM7.1AP
• OBD Reading, writing, checksum correction.
• DCM7.1AP/ DCM7.24 BENCH Reading, writing, checksum
• DCM 6.2AP open model SPC56X

Trucks Delphi ETC3:

• Reading and writing via OBD2 connector via CAN-bus of Delphi ETC3 ECUs used in DAF, Kenworth, Peterbilt, Hyundai trucks.
• DAF/Industrial Delphi ETC3
• Delphi ETC3 REV A/B/C ECUs based on MCU NXP MPC5566 with internal flash memory 3 Mb.
• Reading of map area and writing with checksum correction via CANbus via OBD2 or on the BENCH.
• REV 0 and REV H ECUs are not supported.
• Hyundai Delphi ETC3
• Delphi ETC3 ECUs based on MCU NXP MPC5566 with internal flash memory 3 Mb.
• Reading of map area and writing with checksum correction via CANbus via OBD2 or on the BENCH.

Trucks Delphi DMCI CAN:

• Module for reading and writing by CAN-bus Delphi DMCI ECUs used in DAF and Hyundai trucks.
• ECU is based on MCU Motorola MPC561 with internal flash memory 2.0Mb.
• Allows to read and write calibration area through CAN-bus with checksumm correction on writing.

IVECO Light truck:

• EDC17C69 Bench
• EDC17C49 Bench
• MD1CS069[Support Bench lock Ecu]
• MD1CS089 Bench
• DCU17PC42/PC43 Bench

Isuzu/Transtron:

• 4HK1/6HK1/4JJ1:SH7058
• 6HK1XDIAG/4JJ1XDIAG M4S/L4S:SH72533
• 6HK1/6WG1 M5.3/M5.2:SH72544/SH72546
• -L5.2/L5.3/L5.4:SH72544/SH72546

Kia/Hyundai:

• Modern/Kia heavy-duty truck engine Delphi-ECU: DMCl (chip: MPC561)
• D6CF Delphi ETC3 Series MPC5566-OBD
• Kefico/Denso 2.5L CRDI (SH72546) MB275700-58xx-OBD
• Euro 6 (Denso SH72543)-Bench
• DCM3.7AP

BOSCH EDC:

• DCU17CV51 TC1724 Bench (SAIC/JBC)
• DCU17HD01/DCU2.2 TC1766 (Hino, Cummins, Hyundai, CAT, CASE, Isuzu)
• VD1CC001 Euro 6(Chip: SPC574X, Hino. ISUZU Euro 6 models)
• DCU17PC42/PC43 Bench (IVECO, FOTON, HYUNDAI)
• EDC17CV44/54 OBD/Bench/Open
• EDC17C81 OBD/Bench/Open[Support Bench lock Ecu]
• EDC17C53 OBD/Bench/Open[Support Bench lock Ecu]
• EDC17C55/C63/C04 OBD/Bench/Open[Support Bench lock Ecu]
• EDC17CV41 OBD/Bench/Open(WeiChai, Iveco,Doosan,CASE,New Holland, CLAAS)
• EDC17CV42 Bench MAN
• EDC7UC31 MPC561/562 OBD/Bench
• EDC7C1(lveco, Doosan, etc,series chip:MPC555)
• EDC7C4, EDC17CP15/CP52 Chip:MPC555 OBD
• EDC16UC40 MPC561/562 OBD/Bench
• EDC16C39 MPC561/562 OBD/Bench
• EDC17CP52 TC1797 Bench(Ivevo,Fuso)
• EDC17C69 TC1793 Bench IVECO
• EGC4 TC1797 BGA Bench
• MEG17.9.1X, Chip:TC176211766/179211796 (Bench Mode)
• MEG17.9.2X, Chip:TC17241172817671178211784/1797 (Bench Mode)

BOSCH MD1 Bootloader:

• MD1CE100 AURIX SAK-TC299TP
• MD1CE108 ST-SPC5898
• MD1CS089 SAK-TC299TP
• MD1CS069 SAK-TC299TP
• MD1CC878/868 ST-SPC58XX

CUMMINS:

• 2880
• 2220
• 2250
• 2150
• 2150E
• 876
• 2350
• 2350A
• 2620
• 2670
• 2380（Natural Gas）
• X12N MD1
• 850

Others:

• Continental FAW 52E/91E SPC563X OBD/Open/checksum
• Continental Weichai WISE15/15C SPC564X OBD/Open/checksum
• Continental FAW 32F/36F OBD /checksum
• Econtrols LNG/CNG 3G/4G OBD Model
• Woodward LNG/CNG OBD Model/Recover
• ZF Transmission OBD writing/checksum
• ZF Retarder OBD writing
• WABCO ECAS Reading, writing
• WABCO ABS/EBS Reading, writing
• Knorr ECAS Reading, writing
• Knorr ABS/EBS Reading, writing
• VCU/CBCU/BCM/Instrument writing (FAW, CNHTC, DF, Foton,)

Note:Engine Dance X5 Supports reading and writing of over 300 ECU models of Chinese commercial vehicles, covering almost all electronic control systems of commercial vehicles in China, not listed one by one.

Package includes:

• 1pc x EngineDance X5 Diag Truck Diagnostics
